Quality and construction? Cetus mk3

ease of use? definitly not a Cetus mk3

The black plastic tubes don’t block 100% UV so place it in a dark corner of a room.

Besides light, temperature can also cause degradation.

Oxygen might as well slowly oxidize the photosensitive catalyst.

1. It does expire.

2. I used resin that had expired for a whole year.

3. If it doesn’t print/cure properly it is “expired”. Shouldn’t cause any serious harm to the printer or additional safety hazard. So just go for it.

I still use them and the only reason why I haven’t updated it for a while: don’t fix it if itsn’t broken and nothing in the change logs read like I should update.

Even if you update: there is or will be (didn’t follow it that closely) the debugging mode or how they call it. Not even sure if the A1 even has this DRM sofar or only the X1 series.

BambuLab A1 mini without AMS it is $200. Toss in a hardened steel nozzle ($10 or so) and they are good for Carbon fiber materials.

Construction is pretty similar to the mentioned Cetus MK3 with the difference that BambuLab nailed the usability.

Hope to include printing, especially in metal.

Won’t happen. This requires a debinding oven which is a pretty nasty process involving acids/bases, high pressure and temperature.

There are products like (BASF) Forward AM 316L which can be mailed in for the debinding and sintering process.

I’ve seen some of the flap about Bambu and them closing up the software tool chain. I would like to avoid that sort of thing, for now, openness is better.

You don’t need to update as they are fine. with the current firmware, it is a non-issue.

DRM They limit who can talk what to their printers.

Most noticeably you can only send and start prints (g-code) with their own program over the network. Either bambu studio or a “cloud” gateway from BambuLab. It is no longer possible to do this from within Prusa- or OrcaSlicer.

my take:

1. ~~ for the X1C they allow to install X1Plus firmware. The community asked for it. BambuLab allowed it back then and still does.~~ At the moment rooting an X1C isn’t possible. Either it is a broken promise (“We will give customers the choice to install third party firmware and root system at their own risk.”)or just a temporary issue.

2. BambuLab sad that this will come. Only now that they have done it, most people are starting to notice.

Will report back tomorrow.

One more information: It happens immediately after turning the printer on. the heater output doesn’t need to be enabled in the control interface or by g-code.

here is the schematic: https://github.com/Duet3D/Duet-2-Hardware/blob/master/Duet2/Duet2v1.06/Duet2_Schematic_v1.06.pdf

https://github.com/Duet3D/Duet-2-Hardware/blob/master/Duet_Expansion/Duex5v0.9a/Duex_Schematic_v0.9a.pdf

There is a 74HCT02 which can do up to 20mA so no pulldown resistor is required.

Not looking forward to cut traces on it for troubleshooting. It is an original board (no clone) so it should be exactly the parts in this schematic assuming the linked revision matches the board revision.

I would troubleshoot that hardware first

Was my first instinct as well as I didn’t do any firmware updates prior.

The continuity test doesn’t show a short and the test Duet recommended in one of the documentation was to remove the SD-card. If the issue stays it is a hardware issue. If it is “gone” it isn’t and me removing the SD-card causes this behavior to stop further indicating a software issue. Reading the schematic right now for the first time and I am schoked that there is no ESD-protection at all. Nothing. Just a straight connection from the mosfet to the output… what the hell where they thinking …

Would need to have an in-depth look at the schematic but likely I can’t probe the MOSFET gate voltages in the circuit.

What I could do is probe the signal/heater enable signal from the MCU.

If you have to mix it use mechanical interlocking parts. Like a PLA cavity that is filled with PETG. The PLA & PETG won’t connect/bond but due to the mechanical design, it will still hold together.
